Single Layer Plastic Film Blowing Machine / High Speed Film Blowing Machine

Model

SJ-55

SJ-60

SJ-65

Diameter of Screw

φ55

Φ60

Φ65

Max. Width of Folded Film

200-800

300-1000

300-1200

Single-face Thickness of Film(mm)

0.01-0.10

0.01-0.10

0.01-0.10

Max. Extrusion(kg/h)

75kgs/h

100kgs/h

120kgs/h

L/D

30:1

30:1

30:1

Die head size

Φ80, φ150

Φ120, φ200

Φ150, φ250

Power of Main Motor(kw)

22

37

37

Power of Traction Motor(kw)

1.5

1.5

1.5

Max.line speed(m/min)

100

100

100

Overall Dimension (L x W x H)

6500×2200×4700

7000×2300×5250

7300×2600×5800

Weight(T)

2.5T

3.5T

3.5T

1

Barrel and screw material: BIMETALIC Screw and 38CrMoAl barrel

2

Die HEAD : fixed die head with double vent air ring

3

Gear box: water cooling reducer, hard tooth surface

4

AIR BLOWER :5.5KW(Detal inverter control)

5

single winder : automatic rewinding and automatic changer roll ,control by PLC ,with two air shaft

6

counter of metric

7

Main motor : China motor With inverter control (China BRAND)

8

Heating ring : casting -AL material

9

with pneumatic cylinder on top tower and winder side

10

Line speed :100m/min

11

With Embossing roller

12

With Gusset device

13

Bubble fixer :Aluminium material figuration frame

14

Other low-pressure electrical part : China brand

15

Power supply: 380V,3 phase, 50 HZ/Cycles.

16

UP and down device: inner type up and down, . 1pc

1

CORONA TREATER

2

Rotary die head .

3

Mechanics-screen changer

4

Auto loader
